传感器特性
名称	Sony IMX546 CMOS
快门	Global
靶面尺寸	11.1 mm (Type 2/3″)
分辨率	2840 x 2840 px, 8.1 MP
像元尺寸	2.74 µm (H) x 2.74 µm (V)
帧率	14.8 FPS FPS @ 8.1 MP

物理特性
尺寸	29 x 29 x 45 mm
镜头接口	C-Mount
重量	67 g

接口和电源信息
数据接口	1000BASE-T GigE M12, PoE
数字I/O	8 pin M8 connector
路光耦隔离I/O	1 input, 1 output
路双向可配置非隔离I/O	2 bi-directional
功率要求	PoE (IEEE 802.3af), or 12-24 VDC external
功耗	3.1W via PoE, 2.5W when powered externally

成像特性
缓存容量	128 MB
Image Processing	Gain, gamma, black level, white balance, LUT, CCM, pixel correction, hue, saturation, color space conversion
数据格式	Mono8/10/12/16, Bayer8/10/12/16, RGB8, YUV422, YUV411
Image Modes	Horizontal and vertical binning, decimation, ROI, horizontal and vertical flip
ADC	12 bit
增益范围	0 dB to 48 dB analog and digital
曝光时间范围	30 μs to 10 s

相机功能
User Sets	1 default and 2 custom user set
File System Size	16 MB
Chunk Data	Timestamp, frame counter, offset X/Y, width/height, exposure time, gain, black level, line status, sequencer set
Event Data	Acquisition start/end, exposure start/end, line rise/fall, error
Counter & Timer	2 counters and 2 timers
Sequencer	Exposure time, gain
Synchronization	Software trigger, hardware trigger, PTP (IEEE 1588)

标准和认证
兼容	GigE Vision v2.0
认证	CE, FCC, RoHS, REACH, WEEE
存储温度	-30 to 60°C
工作温度	-20 to 55°C
湿度	Operating: 20% ~ 80%, relative, non-condensing
冲击和振动标准	DIN EN 60068-2-27, DIN EN 60068-2-64
保修	3 year
